YOKOGAWA DY150 User Manual

9-38
IM 01F06A00-01E
9. GENERAL DESCRIPTION
 Remote Type Converter (DYA)
Unit: mm
(approx. inch)
Weight: 1.9 kg (4.19lb), 4.1 kg (9.04lb) for /E1.
Note: For flowmeters with indicator, add 0.2 kg.(0.44lb), 0.3 kg (0.66lb) for /E1.
4.5(0.18)
59(2.32) 59(2.32)
125(4.92)
103.5(4.07)
74(2.91)
φ94(3.70)
208.5(8.21)
87.5(3.44)
WITH INDICATOR
CLAMP
Only for
TIIS Explosion proof
KEMA Explosion proof
SAA Explosion proof
ELECTRICAL
CONNECTION
(both sides)
EARTH
TERMINAL
 Signal Cable for Remote Type (DYC)
Unit: mm
(approx. inch)
(Black) (White) (Red)
(Red) (White)
(Black)
80
(3.15)
70
(2.76)
70
(2.76)
80
(3.15)
φ9.2
(0.36)
(Blue)
60
(2.36)
25
(0.98)
95
(3.74)
60
(2.36)
50
(1.97)
20
(0.79)
Sepcified
Length (L)
30m (max.)
DYC
Flowmeter
Converter
Color
Cable Color and Terminal
Terminal
Yellow
(*1)
Red
White
Black
Blue
Flow meter
T
A
B
Converter
T
A
B
C
(Yellow)
(Yellow)
(*1) Only for /MV
50
(1.97)
