Transmitter installation
Quick Reference Instruction Manual
Installation
IM01U10A00-00EN-R, 2nd edition, 2017-08-29
27 / 54
7. Tighten screws.
8. Screw display cover back onto transmitter housing.
9. Using an Allen wrench (size: 3.0), turn the locking screw on display screw plug
counter-clockwise to tighten.
