Quick Reference Instruction Manual
Installation
Installation check list
28 / 54
IM01U10A00-00EN-R, 2nd edition, 2017-08-29
6.5 Installation check list
The following checks must be performed once the flow meter is installed in the pipe:
Check Performed?
State and specification of device
▪ Flow meter checked for external damage?
▪ Does flow meter meet the specifications of the measuring point
(medium temperature, process pressure, ambient temperature,
measuring range, etc.)?
Installation
▪ Does flow direction on flow meter correspond to the actual flow di-
rection in the pipe?
▪ If not, has the appropriate parameter in the transmitter menu been
switched?
▪ Do measuring point number and nameplate labeling match the in-
stallation site?
▪ Do mounting position and installation match usage (measurement
of gas, liquid) in the process environment and under process con-
ditions?
▪ Is meeting the permissible ambient temperature for the transmitter
ensured?
Process environment and conditions
▪ Is the flow meter protected from environmental influences (precipi-
tation, direct insolation)?
