YOKOGAWA TY710 User Manual

76
Continuity Check
Maximum Reading 5000
Range Resolution Range of Operation
Measuring
Current
Open-loop
Voltage
Input Protective
Voltage
500Ω 0.1Ω
The buzzer turns on
for resistances lower
than100±50Ω.
Approx.
0.5mA
<5V 1000V rms
Diode Test
Range Resolution Accuracy
Measuring Current
(Vf=0.6V)
Open-loop
Voltage
Input Protective
Voltage
2.4V 0.0001V 1+2 Approx. 0.5mA <5V 1000V rms
Temperature Measurement TEMP
Range Resolution Accuracy
Input Protective
Voltage
-200to1372°C 0.1°C 1+1.5°C 1000V rms
UseoptionalTemperatureProbe:ThermocoupleTypeK
Capacitor Measurement
Maximum Reading 5000
Range Resolution Accuracy Input Protective Voltage
5nF 0.001nF
1+5
*1
1000V rms
50nF 0.01nF
500nF 0.1nF
5μF 0.001μF
50μF 0.01μF
500μF 0.1μF 2+5
5mF 0.001mF
3+5
50mF 0.01mF
*1:Accuracyisspeciedafterzeroadjustment(capacitor).
