77
Frequency Measurement Hz
AC Coupling, Maximum Reading 9999
Range(AUTO) Resolution Accuracy
2.000 to 9.999Hz 0.001Hz
0.02+1
*1
9.00 to 99.99Hz 0.01Hz
90.0 to 999.9Hz 0.1Hz
0.900 to 9.999kHz 0.001kHz
9.00 to 99.99kHz 0.01kHz *2
Accuracy
*1:At10to100%ofinputvoltageorcurrentrange
*2:At40to100%ofinputvoltageorcurrentrange
Duty cycle ratio %
Range Resolution Accuracy
10 to 90% 1% ±1%*1
Accuracy
*1:At10.00Hzto500.0Hz,squarewave
At 40 to 100% of input voltage or current range
PeakHoldP•H
Model TY720 only
Maximum Reading 5000
Range Accuracy Response Time Maximum
DCV, DCA ±100digit >250μS
