YOKOGAWA TY710 User Manual

83
SymbolandUnit Description
Appears when in DC-mode measurement
Appears when in AC-mode measurement
+ AppearswheninDC+AC-modemeasurement
– Appears when the polarity is negative
Appears when in diode test
Appears when in continuity check
Relative calculation indicator
R•H Fixed ranges indicator
AUTO AUTOrangeindicator
DATA HOLD indicator
AUTOHOLDindicator
PEAKHOLDindicator
Lit when in MIN/MAX/AVG-mode
Lit when in MIN/MAX/AVG-mode
Lit when in MIN/MAX/AVG-mode
Lit when in Memory function
AUTOOFF Auto power off indicator
RMS Appears in RMS mode
LP-Ω AppearsinLowPower-Ωmeasurement
Filter Appearswhilelterison
Shift Appears while the SHIFT key is held down
nF,μF,mF Unitforcapacitancemeasurement
mV, V Unitforvoltagemeasurement
μA,mA,A Unitforcurrentmeasurement
MΩ,kΩ,Ω Unitforresistancemeasurement
°C Unitfortemperaturemeasurement
kHz, Hz Unitforfrequencymeasurement
dB, dBm Decibel calculation indicator
% (Main-display) Unitforpercentagecalculation
% (Sub- display) Unitfordutycycleratiocalculation
mV, V (Sub- display) Unitforvoltagemeasurement(dB
V
, Hz
V
)
s (Sub- display) UnitforrecordingtimewheninMIN/MAX/AVG-mode
(Sub- display)
Recording time indicator when in MIN/MAX/AVG-mode
Number of saved data indicator
Reference value indicator when relative calculation
Duty cycle ratio indicator
Voltage value (dB
V
, Hz
V
) indicator
Reference resistance value (dBm) indicator
OL Overrange Indicator
Appears when the batteries become low
Bar graph indicator, Range indicator
