YOKOGAWA UT35A User Manual

IM 05P01D31-11EN page 2/12
n
Mounting the Instrument Main Unit
Provideaninstrumentedpanelsteelsheetof1to10mmthickness.
Afteropeningthemountingholeonthepanel,followtheproceduresbelowtoinstall
the controller:
1) Insertthe controller intothe opening fromthe front of the panel so that the
terminalboardontherearisatthefarside.
2) Setthebracketsinplaceonthetopandbottomofthecontrollerasshowninthe
gurebelow,thentightenthescrewsofthebrackets.Takecarenottoovertighten
them.
Bracket
(top mounting hardware)
Terminal board
Bracket
(bottom mounting hardware)
Panel
Insert a screwdriver into the
brackets to tighten the screws.
Direction to insert the
controller
Appropriate
tightening torque:
0.25 N•m
Insert the controller
into the opening at
the front of the panel.
CAUTION
• Tighten the screws with appropriate tightening torque within 0.25
N•m. Otherwise it may cause the case deformation or the bracket
damage.
• Make sure that foreign materials do not enter the inside of the
instrument through the case’s slit holes.
n
External Dimensions and Panel Cutout Dimensions
(25)
(53) (2.09)
[(N-1)×96+92]
117 (4.61) min.
145 (5.71)
min.
+0.8
0
+0.8
0
92
“N” stands for the number of controllers to be
installed.
However, the measured value applies if N≥5.
65 (2.56)
20 (0.79)
11
(0.43)
UT35A
1 to 10 mm (0.04 to 0.39 inch) (panel thickness)
Bracket
Bracket
94.6 (3.72) 91.6 (3.61)
105.2 (4.14)
Unit: mm (approx. inch)
96 (3.78)
96 (3.78)
• General mounting • Side-by-side close mounting
Terminal cover
Normal tolerance:
±(value of JIS B 0401-1998 tolerance class IT18)/2
+0.8
0
92
+0.03
0
(3.62 )
(0.98)
+0.03
0
(3.62 )
+0.8
0
92
+0.03
0
(3.62 )
([(N-1)×3.78+3.62] )
+0.03
0
[(N-1)×48+45]
+0.6
0
65 (2.56)
48 (1.89)
11 (0.43)
UT32A
1 to 10 mm (0.04 to 0.39 inch) (panel thickness)
Bracket
Bracket
Terminal cover
94.6 (3.72)
96 (3.78)
105.2 (4.14)
Unit: mm (approx. inch)
70 (2.76)
min.
(25)
145 (5.71)
min.
+0.6
0
45
(53) (2.09)
+0.8
0
92
• General mounting
• Side-by-side close mounting
20 (0.79)
91.6 (3.61)
“N” stands for the number of controllers to be
installed.
However, the measured value applies if Nr5.
Normal tolerance:
±(value of JIS B 0401-1998 tolerance class IT18)/2
+0.03
0
(3.62 )
+0.02
0
(1.77 )
(0.98)
+0.8
0
92
+0.03
0
(3.62 )
([(N-1)×1.89+1.77] )
+0.02
0
4. HardwareSpecications
WARNING
This instrument is for Measurement Category I (CAT.I). Do not use it
for measurements in locations falling under Measurement Catego-
ries II, III, and IV.
Internal Wiring
Outlet
Entrance IV
Cable
III
T
I
II
Category
Measurement
category
Description Remarks
I CAT.I
For measurements performed on circuits not
directlyconnectedtoMAINS.
-
II CAT.II
For measurements performed on circuits di-
rectlyconnectedtothelow-voltageinstallation.
Appliances,portableequip-
ments, etc.
III CAT.III
Formeasurementsperformedinthebuilding
installation.
Distributionboard,circuit
breaker,etc.
IV CAT.IV
For measurements performed at the source of
thelow-voltageinstallation.
Overheadwire,cable
systems, etc.
n
InputSpecications
●UniversalInput(Equippedasstandard)
• Numberofinputs:1
• Inputtype,instrumentrange,andmeasurementaccuracy:Seethetablebelow,
Input Type
Instrument Range
Accuracy
ºC ºF
Thermo-
couple
K
-270.0to1370.0ºC -450.0to2500.0ºF ±0.1%ofinstrumentrange±1digitfor
0°Cormore
±0.2%ofinstrumentrange±1digitfor
lessthan0°C
±2%ofinstrumentrange±1digitfor
lessthan-200.0°CofthermocoupleK
±1%ofinstrumentrange±1digitfor
lessthan-200.0°CofthermocoupleT
-270.0to1000.0ºC -450.0to2300.0ºF
-200.0to500.0ºC -200.0to1000.0ºF
J -200.0to1200.0ºC -300.0to2300.0ºF
T
-270.0to400.0ºC -450.0to750.0ºF
0.0to400.0ºC -200.0to750.0ºF
B 0.0to1800.0ºC 32to3300ºF
±0.15%ofinstrumentrange±1digit
for400°Cormore
±5%ofinstrumentrange±1digitfor
lessthan400°C
S 0.0to1700.0ºC 32to3100ºF
±0.15%ofinstrumentrange±1digit
R 0.0to1700.0ºC 32to3100ºF
N -200.0to1300.0ºC -300.0to2400.0ºF
±0.1%ofinstrumentrange±1digit
±0.25%ofinstrumentrange±1digit
forlessthan0°C
E -270.0to1000.0ºC -450.0to1800.0ºF ±0.1%ofinstrumentrange±1digitfor
0°Cormore
±0.2%ofinstrumentrange±1digitfor
lessthan0°C
±1.5%ofinstrumentrange±1digitfor
lessthan-200.0°CofthermocoupleE.
L -200.0to900.0ºC -300.0to1600.0ºF
U
-200.0to400.0ºC -300.0to750.0ºF
0.0to400.0ºC -200.0to1000.0ºF
W 0.0to2300.0ºC 32to4200ºF
±0.2%ofinstrumentrange±1digit
(Note2)
Platinel 2 0.0to1390.0ºC 32.0to2500.0ºF ±0.1%ofinstrumentrange±1digit
PR20-40 0.0to1900.0ºC 32to3400ºF
±0.5%ofinstrumentrange±1digitfor
800°Cormore
Accuracyisnotguaranteedforless
than800°C.
W97Re3-
W75Re25
0.0to2000.0ºC 32to3600ºF ±0.2%ofinstrumentrange±1digit
RTD
JPt100
-200.0to500.0ºC -300.0to1000.0ºF
±0.1%ofinstrumentrange±1digit
(Note1)
-150.00to150.00ºC -200.0to300.0ºF ±0.1%ofinstrumentrange±1digit
Pt100
-200.0to850.0ºC -300.0to1560.0ºF
±0.1%ofinstrumentrange±1digit
(Note1)
-200.0to500.0ºC -300.0to1000.0ºF
-150.00to150.00ºC -200.0to300.0ºF ±0.1%ofinstrumentrange±1digit
Standardsignal
0.400to2.000V
±0.1%ofinstrumentrange±1digit
1.000to5.000V
4.00to20.00mA
DCvoltage/current
0.000to2.000V
0.00to10.00V
0.00to20.00mA
-10.00to20.00mV
0.0to100.0mV
Theaccuracyisthatinthestandardoperatingconditions:23±2°C,55±10%RH,andpower
frequencyat50/60Hz.
Note
1: ±0.3°C±1digitintherangebetween0and100°C,±0.5°C±1digitintherange
 between-100and200°C.
Note2: W:W-5%Re/W-26%Re(HoskinsMfg.Co.).ASTME988
•Inputsampling(control)period:200ms
• Burnout detection:
  FunctionsatTC,RTD,andstandardsignal.
  Upscale,downscale,andoffcanbespecied.
  Forstandardsignal,burnoutisdeterminedtohaveoccurredifitis0.1Vor0.4
 mAorless.
•Inputbiascurrent:0.05µA(forTCorRTD)
•Measuredcurrent(RTD):About0.16mA
• Input resistance:
  TCormVinput:1MΩormore
  Vinput:About1MΩ
  mAinput:About250Ω
•Allowablesignalsourceresistance:
  TCormVinput:250Ωorless
  Effectsofsignalsourceresistance:0.1µV/Ωorless
  DCvoltageinput:2kΩorless
  Effectsofsignalsourceresistance:About0.01%/100Ω
• Allowablewiringresistance:
  RTDinput:Max.150Ω/wire(Theconductorresistancebetweenthethreewires
 shallbeequal.)
  Wiringresistanceeffect:±0.1ºC/10Ω
• Allowableinputvoltage/current:
  TC,mV,mAandRTDinput:±10VDC
  Vinput:±20VDC
  mAinput:±40mA
• Noiserejectionratio:
  Normalmode:40dBormore(at50/60Hz)
  Commonmode:120dBormore(at50/60Hz)
  For 100-240 VAC, the power frequency can be set manually.Automatic
 detectionisalsoavailable.
  For24VAC/DC,thepowerfrequencycanbesetmanually.
• Referencejunctioncompensationerror:
  ±1.0ºC(15to35ºC)
  ±1.5ºC(-10to15ºCand35to50ºC)
• Applicablestandards:JIS/IEC/DIN(ITS-90)forTCandRTD
n
AnalogOutputSpecications
• Numberofoutputs:
  Controloutput:1
  Cooling-side control output of Heating/cooling type (Retransmission output
 terminal):1
• Outputtype:Currentoutputorvoltagepulseoutput
• Currentoutput:4to20mADCor0to20mADC/loadresistanceof600Ωorless
• Currentoutputaccuracy:±0.1%ofspan(±5%ofspanfor1mAorless)
  Theaccuracyisthatinthestandardoperatingconditions:23±2°C,55±10%RH,
 andpowerfrequencyat50/60Hz.
• Voltagepulseoutput:
  Use:Timeproportionaloutput
  On-voltage:12Vormore/loadresistanceof600Ωormore
  Off-voltage:0.1VDCorless
  Timeresolution:10msor0.1%ofoutput,whicheverislarger
n
StepResponseTimeSpecications
Within1s(63%ofanalogoutputresponsetimewhenastepchangeof10to90%of
inputspanisapplied)
n
RelayContactOutputSpecications
• Contacttypeandnumberofoutputs:
  Controloutput:contactpoint1c;1point
  Heating/coolingtype:contactpoint1a;2pointsforbothheatingandcoolingsides
  Alarmoutput:contactpoint1a;3points(commonisindependent)
• Contactrating:
  Contactpoint1c(controloutput):250VAC,3Aor30VDC,3A(resistanceload)
  Contactpoint1a(controloutput):240VAC,3Aor30VDC,3A(resistanceload)
  Contactpoint1a(alarmoutput):240VAC,1Aor30VDC,1A(resistanceload)
• Use:Timeproportionaloutput,alarmoutput,FAILoutput,etc.
• Timeresolutionofcontroloutput:10msor0.1%ofoutput,whicheverislarger
Note:Thiscannotbeusedforasmallloadof10mAorless.
n
PositionProportionalOutputSpecications
• Positionsignalinput:
  Slideresistance:100Ωto2.5kΩoftotalresistance
  100%sideandslideline:withdisconnectiondetection
  0%side:withoutdisconnectiondetection
  Currentinput:4to20mA(withdisconnectiondetection)
• Samplingperiod:50ms
• Measurementresolution:0.1%ofinputspan
• Position proportional relay output:
UT35A:contactpoint1a;2points,250VAC,3Aor30VDC,3A(resistanceload)
UT32A:contactpoint1a;2points,240VAC,3Aor30VDC,3A(resistanceload)
Note:Thiscannotbeusedforasmallloadof10mAorless.
n
RetransmissionOutputSpecications
• Number ofoutputs: Retransmission output; 1,sharedwith15VDCloop power
supplyorCooling-sidecontroloutput.
• Currentoutput:4to20mADCor0to20mADC/loadresistanceof600Ωorless
• Currentoutputaccuracy:±0.1%ofspan(±5%ofspanfor1mAorless)
  Theaccuracyisthatinthestandardoperatingconditions:23±2°C,55±10%RH,
  andpowerfrequencyat50/60Hz.
n
15VDCLoopPowerSupplySpecications
(SharedwithretransmissionoutputorCooling-sidecontroloutput.)
• Powersupply:14.5to18.0VDC
• Maximumsupplycurrent:About21mA(withshort-circuitcurrentlimitingcircuit)
n
ContactInputSpecications
• Numberofinputs:SeethetableofModelandSufxCodes.
• Inputtype:No-voltagecontactinputortransistorcontactinput
• Inputcontactrating:12VDC,10mAormore
  Useacontactwithaminimumon-currentof1mAormore.
• ON/OFFdetection:
  No-voltagecontactinput:
  Contactresistanceof1kΩorlessisdeterminedas“ON”andcontact
  resistanceof50kΩormoreas“OFF.”
Transistor contact input:
  Inputvoltageof2Vorlessisdeterminedas“ON”andleakagecurrentmust
  notexceed100µAwhen“OFF.”
• Minimumstatusdetectionholdtime:Controlperiod+50ms
• Use:SPswitch,operationmodeswitch,andeventinput
n
TransistorContactOutputSpecications
• Numberofoutputs:SeethetableofModelandSufxCodes.
• Outputtype:Opencollector(SINKcurrent)
• Outputcontactrating:Max.24VDC,50mA
• Outputtimeresolution:200ms
n
HeaterBreakAlarmSpecications
• Numberofinputs:2
• Numberofoutputs:2(transistorcontactoutput)
• Use:Measurestheheatercurrentusinganexternalcurrenttransformer(CT)and
generatesaheater breakalarmwhenthemeasuredvalueis lessthanthebreak
detectionvalue.
• Currenttransformerinputresistance:About9.4Ω
• Currenttransformerinputrange:0.0to0.1Arms(0.12Armsormorecannotbeap-
plied.)
• Heatercurrentsettingrange:OFF,0.1to300.0Arms
  Heatercurrentmeasuredvaluedisplayrange:0.0to360.0Arms
 Note:TheCTratiocanbeset.CTratiosettingrange:1to3300
• RecommendedCT:CTfromU.R.D.,Ltd.
  CTL-6-S-H:CTratio800,measurablecurrentrange:0.1to80.0Arms
  CTL-12L-30:CTratio3000,measurablecurrentrange:0.1to180.0Arms
• Heatercurrentmeasurementperiod:200ms
• Heatercurrent measurementaccuracy:±5% of currenttransformer input range
span±1digit(CTerrorisnotincluded.)
• Heatercurrentdetectionresolution:Within1/250ofcurrenttransformerinputrange
span
• BreakdetectionOn-time:Min.0.2second(fortimeproportionaloutput)
n
24VDCLoopPowerSupplySpecications
• Use:Powerissuppliedtoa2-wiretransmitter.
• Powersupply:21.6to28.0VDC
• Ratedcurrent:4to20mADC
• Maximumsupplycurrent:About30mA(withshort-circuitcurrentlimitingcircuit.)

YOKOGAWA UT35A Specifications

General

Brand	YOKOGAWA
Model	UT35A
Category	Controller
Language	English
