YOKOGAWA WT310 User Manual

2-22
IM WT310-02EN
You can also connect to the circuit under measurement by placing a terminal block near the WT310
and connecting the power cables and voltage measurement cables to the terminal block.
Terminal block
2.9 Wiring the Circuit under Measurement for Direct Input

YOKOGAWA WT310 Specifications

General

Model	WT310
Category	Digital Power Meter
Current Measurement Range	0.5 mA to 20 A
Weight	Approx. 3.5 kg
Voltage Measurement Range	15 V to 600 V
Frequency Range	100 kHz
Basic Accuracy	0.1%
Power Accuracy	0.1%
Display	LCD
Interfaces	USB, RS-232, GP-IB
Input Elements	1
Dimensions	213 mm x 88 mm x 346 mm
