TABLE 5: DNP036 COOLING CAPACITIES - 3 TON
TEMPERATURE
OF AIR ON
CONDENSER COIL
AIR ON EVAPORATOR COIL
1,200 CFM 1,350 CFM
WB °F WB °F
72 67 62 57 72 67 62 57
85 °F
NET CAP.
MBH
43.3 39.9 37.4 36.7 44 40.5 38 37.2
TOTAL POWER
INPUT kW
2.932.89 2.9 2.883.083.053.063.04
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 29.5 35.8 37.4 36.7 31.8 38.4 38 37.2
83 26 32.3
37.4 36.7 27.8 34.4 38 37.2
80 22.5 28.8 34.8 35.6 23.8 30.4 36.7 36.7
77 19 25.3 31.3 32.1 19.9 26.4 32.7 32.7
74 15.5 21.8 27.8 28.6 15.9 22.5 28.7 28.7
71 - 18.3 24.3 25.1 - 18.5 24.7 24.7
68 - 14.8 20.8 21.6 - 14.5 20.7 20.7
95 °F
NET CAP.
MBH
41.4 37.1 35.7 35.3 42.5 38 36.6 36.2
TOTAL POWER
INPUT kW
3.22 3.27 3.18 3.15 3.32 3.37 3.28 3.25
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 28.5 34.8 35.7 35.3 31 36.9 36.6 36.2
83 25 31.3
35.7 35.3 27 33.7 36.6 36.2
80 21.5 27.8 33.5 33.9 23 29.7 25.5 35.5
77 18 24.3 30 30.4 19 25.7 31.5 31.5
74 14.5 20.8 26.5 26.9 15 21.7 17.6 27.5
71 - 17.3 23 23.4 - 17.7 23.6 23.5
68 - 13.8 19.5 19.9 - 13.8 19.6 19.5
105 °F
NET CAP.
MBH
38.5 34.8 33.9 33.6 39.6 35.8 34.8 34.5
TOTAL POWER
INPUT kW
3.613.61 3.5 3.483.733.723.613.59
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 27.6 33.6 33.9 33.6 29.9 35.1 34.8 34. 5
83 24.1 30.1 33.9 33.6 26 32.4 34.8 34.5
80 20.6 26.6 32 32.2 22 28.4 33.9 33.8
77 17.1 23.1 28.5 28.7 18 24.4 29.9 29.8
74 13.6 19.6 25 25.2 14 20.5 25.9 25.8
71 - 16.1 21.5 21.7 - 16.5 21.9 21.8
68 - 12.6 18 18.2 - 12.5 18 17.9
115 °F
NET CAP.
MBH
35.6 32.6 32.2 31.9 36.7 33.5 33.1 32.8
TOTAL POWER
INPUT kW
4.01 3.95 3.82 3.8 4.14 4.07 3.93 3.92
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 26.6 32.4 32.2 31.9 28.9 33.4 33.1 32.8
83 23.1 28.9 32.2 31.9 24.9 31.1 33.1 32.8
80 19.6 25.4 30.6 30.6 21 27.1 32.3 32.1
77 16.1 21.9 27.1 27.1 17 23.2 28.3 28.1
74 12.6 18.4 23.6 23.6 13 19.2 24.3 24.1
71 - 14.9 20.1 20.1 - 15.2 20.3 20.2
68 - 11.4 16.6 16.6 - 11.2 16.3 16.2
125 °F
NET CAP.
MBH
32.8 30.2 30.4 30.1 33.7 31.2 31.3 30
TOTAL POWER
INPUT kW
4.4 4.3 4.1 4.1 4.5 4.4 4.3 4.2
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 25.6 31.2 30.4 30.1 27.9 31.6 31.3 31
83 22.1 27.7
30.4 30.1 23.9 29.9 31.3 31
80 18.6 24.2 19.1 28.9 19.9 25.9 30.6 30.4
77 15.1 20.7 25.6 25.4 15.9 21.9 26.6 26.4
74 11.6 17.2 22.1 21.9 12 17.9 22.7 22.5
71 - 13.7 18.6 18.4 - 13.9 18.7 18.5
68 - 10.2 15.1 14.9 - 9.9 14.7 14.5
1.
These capacities are net capacities (the indoor fan heat is deducted).
ALL SENSIBLE CAPACITY
