036-21366-007-A-1205
14 Unitary Products Group
TABLE 8: DNP060 COOLING CAPACITIES - 5 TON
TEMPERATURE
OF AIR ON
CONDENSER COIL
AIR ON EVAPORATOR COIL
1,500 CFM 1,800 CFM
WB °F WB °F
72 67 62 57 72 67 62 57
85 °F
NET CAP.
MBH
63.5 57.6 52.7 53.1 64.3 58.3 53.3 53.7
TOTAL POWER
INPUT kW
4.49 4.44 4.38 4.27 4.68 4.63 4.57 4.45
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 39.4 47.5 52.7 53.1 41.4 49.6 53.3 53.7
83 35.0 43.2 50.9 53.1 36.1 44.3 52.0 53.7
80 30.6 38.8 46.5 50.5 30.7 38.9 46.6 50.7
77 26.3 34.4 42.1 46.2 25.4 33.5 41.2 45.3
74 21.9 30.0 37.7 41.8 20.0 28.2 35.9 39.9
71 -- 25.7 33.4 37.4 -- 22.8 30.5 34.6
68 -- 21.3 29.0 33.1 -- 17.4 25.1 29.2
95 °F
NET CAP.
MBH
60.6 56.0 52.1 51.5 61.2 56.6 52.6 52.0
TOTAL POWER
INPUT kW
4.96 4.90 4.80 4.73 5.12 5.05 4.95 4.88
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 38.2 46.6 52.1 51.5 43.3 52.6 52.6 52.0
83 33.9 42.2 49.8
51.5 38.0 47.2 52.6 52.0
80 29.5 37.8 45.4 48.7 32.6 41.9 50.3 52.0
77 25.1 33.5 41.1 44.4 27.3 36.5 44.9 46.7
74 20.7 29.1 36.7 40.0 21.9 31.1 39.5 41.3
71 -- 24.7 32.3 35.6 -- 25.8 34.2 35.9
68 -- 20.3 27.9 31.2 -- 20.4 28.8 30.6
105 °F
NET CAP.
MBH
57.6 53.3 49.5 49.3 58.4 54.1 50.2 50.0
TOTAL POWER
INPUT kW
5.52 5.43 5.34 5.27 5.69 5.60 5.51 5.43
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 37.1 45.3 49.5 49.3 42.6 51.8 50.2 50.0
83 32.7 40.9 48.4
49.3 37.2 46.4 50.2 50.0
80 28.4 36.6 44.1 46.4 31.8 41.1 49.1
50.0
77 24.0 32.2 39.8 42.1 26.5 35.7 43.7 44.7
74 19.6 27.8 35.4 37.7 21.1 30.3 38.3 39.3
71 -- 23.4 31.0 33.3 -- 25.0 33.0 33.9
68 -- 19.1 26.6 29.0 -- 19.6 27.6 28.6
115 °F
NET CAP.
MBH
54.6 50.6 46.9 47.1 55.7 51.6 47.9 48.0
TOTAL POWER
INPUT kW
6.07 5.97 5.89 5.81 6.26 6.16 6.07 5.99
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 36.0 44.0 46.9 47.1 41.8 51.0 47.9 48.0
83 31.6 39.7
46.9 47.1 36.4 45.6 47.9 48.0
80 27.2 35.3 42.9 44.2 31.1 40.3
47.9 48.0
77 22.8 30.9 38.5 39.8 25.7 34.9 42.5 42.7
74 18.5 26.5 34.1 35.4 20.3 29.5 37.1 37.3
71 -- 22.2 29.7 31.0 -- 24.2 31.8 31.9
68 -- 17.8 25.4 26.7 -- 18.8 26.4 26.6
125 °F
NET CAP.
MBH
51.6 47.9 44.4 44.9 52.9 49.1 45.5 46.0
TOTAL POWER
INPUT kW
6.62 6.51 6.43 6.35 6.82 6.71 6.62 6.54
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 34.8 42.8 44.4 44.9 41.0 50.2 45.5 46.0
83 30.5 38.4 45.5 44.9 35.6 44.8 45.5 46.0
80 26.1 34.0 41.6 41.9 30.3 39.5 46.7
46.0
77 21.7 29.6 37.2 37.5 24.9 34.1 41.3 40.7
74 17.3 25.3 32.8 33.1 19.6 28.7 35.9 35.3
71 -- 20.9 28.4 28.7 -- 23.4 30.6 29.9
68 -- 16.5 24.1 24.4 -- 18.0 25.2 24.6
1.
These capacities are net capacities (the indoor fan heat is deducted).
ALL SENSIBLE CAPACITY
