036-21366-007-A-1205
Unitary Products Group 13
TABLE 7: DNP048 COOLING CAPACITIES - 4 TON
TEMPERATURE
OF AIR ON
CONDENSER COIL
AIR ON EVAPORATOR COIL
1,400 CFM 1,600 CFM
WB °F WB °F
72 67 62 57 72 67 62 57
85 °F
NET CAP.
MBH
54.0 49.2 45.6 45.9 55.2 50.4 46.6 46.9
TOTAL POWER
INPUT kW
3.69 3.66 3.62 3.57 3.85 3.83 3.79 3.73
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 35.8 43.7 45.6 45.9 39.1 47.7 46.6 46.9
83 31.7 39.6 44.6 45.3 34.5 43 46.6 46.9
80 27.7 35.6 42.4 43.6 29.8 38.3 45.7 46.9
77 23.6 31.6 38.4 39.5 25.1 33.7 41 42.3
74 19.6 27.5 34.3 35.5 20.5 29 36.3 37.6
71 - 23.5 30.3 31.4 - 24.3 31.7 32.9
68 - 19.4 26.2 27.4 - 19.7 27 28.3
95 °F
NET CAP.
MBH
51.8 46.8 43.8 44.0 51.9 46.9 43.9 44.2
TOTAL POWER
INPUT kW
4.07 4.04 4.01 3.99 4.21 4.18 4.15 4.12
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 35.4 42.9 43.8 44.0 38.4 46.4 43.9 44.2
83 31.4 38.9 42.8 43.2 33.8 41.7
43.9 44.2
80 27.4 34.9 40.9 41.5 29.1 37.1 43.5 44.2
77 23.3 30.8 36.8 37.5 24.4 32.4 38.8 39.5
74 19.3 26.8 32.8 33.4 19.8 27.7 34.1 34.8
71 - 22.7 28.7 29.4 - 23.1 29.5 30.2
68 - 18.7 24.7 25.4 - 18.4 24.8 25.5
105 °F
NET CAP.
MBH
48.7 44.3 41.4 41.7 49.2 44.7 41.8 42.1
TOTAL POWER
INPUT kW
4.49 4.45 4.38 4.34 4.63 4.59 4.51 4.48
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 34.1 41.3 41.4 41.7 37.1 4.44 41.8 42.1
83 30.0 37.7 40.7 41.1 32.4 40.6
41.8 42.1
80 26.0 33.6 38.9 39.4 27.8 35.9 41.6
42.1
77 22.0 29.6 34.9 35.3 23.1 31.3 36.9 37.4
74 17.8 25.6 30.8 31.3 18.4 26.6 32.3 32.7
71 - 21.5 26.8 27.3 - 21.9 27.6 28.1
68 - 17.5 22.8 23.2 - 17.3 22.9 23.4
115 °F
NET CAP.
MBH
45.7 41.8 39.1 39.4 46.4 42.5 39.7 40
TOTAL POWER
INPUT kW
4.91 4.86 4.74 4.70 5.05 5 4.87 4.83
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 32.7 39.7 39.1 39.4 35.8 42.5 39.7 40
83 28.7 36.5 38.7 38.9 31.1 39.5
39.7 40
80 24.6 32.4 37.0 37.2 26.4 34.8
39.7 40
77 20.6 28.4 32.9 33.2 21.8 30.1 35 35.3
74 16.6 24.4 28.9 29.1 17.1 25.5 30.4 30.6
71 - 20.3 24.9 25.1 - 20.8 25.7 26
68 - 16.3 20.8 21.1 - 16.2 21 21.3
125 °F
NET CAP.
MBH
42.7 39.3 36.8 37.0 43.6 40.2 37.6 37.9
TOTAL POWER
INPUT kW
4.3 5.3 5.1 5.0 5.5 5.4 5.2 5.2
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 31.4 38.0 36.8 37.0 34.5 40.5 37.6 37.9
83 27.3 35.3 36.7 36.8 29.8 38.4 37.6 37.9
80 23.3 31.2 35.1 35.1 25.1 33.7
37.6 37.9
77 19.2 27.2 31.0 31.0 20.5 29 33.2 33.2
74 15.2 23.1 27.0 27.0 15.8 24.4 28.5 28.5
71 - 19.1 22.9 23.0 - 19.7 23.8 23.9
68 - 15.1 18.9 18.9 - 15 19.2 19.2
1.
These capacities are net capacities (the indoor fan heat is deducted).
ALL SENSIBLE CAPACITY
