TABLE 3: DNP024 COOLING CAPACITIES - 2 TON (CONT’D)
AIR ON
EVAPORATOR
COIL
TEMPERATURE OF AIR ON CONDENSER COIL
125°F
NET
CAP.
MBH
POWER
INPUT
KW
SENSIBLE CAPACITY
1
ENTERING DRY BULB, °F
CFM
WB
°F
86 83 80 77 74 71 68
600
72 18.4 2.5 13.1 11.4 9.7 8.0 6.3 #N/A #N/A
67 16.6 2.4
16.7 15.0 13.3 11.5 9.8 8.1 6.4
62 16.2 2.5
16.2 16.2 14.8 13.1 11.4 9.6 7.9
57 16.5 2.5
16.5 16.5 14.9 13.2 11.5 9.8 8.1
700
72 19.3 2.6 14.6 12.5 10.5 8.5 6.5 #N/A #N/A
67 17.4 2.5
17.8 16.4 14.4 12.4 10.3 8.3 6.3
62 17.0 2.5
17.0 17.0 16.0 14.0 12.0 10.0 7.9
57 17.2 2.5
17.2 17.2 16.2 14.2 12.1 10.1 8.1
800
72 20.1 2.6 16.0 13.7 11.3 9.0 6.7 #N/A #N/A
67 18.1 2.5
18.9 17.9 15.5 13.2 10.9 8.5 6.2
62 17.7 2.5
17.7 17.7 17.3 15.0 12.6 10.3 8.0
57 18.0 2.5
18.0 18.0 17.5 15.1 12.8 10.5 8.1
900
72 20.4 2.6 17.1 14.5 11.8 9.2 6.5 #N/A #N/A
67 18.3 2.6
18.7 18.6 16.2 13.5 10.9 8.2 5.6
62 17.9 2.6
17.9 17.9 17.7 15.0 12.4 9.7 7.1
57 18.2 2.6
18.2 18.2 17.9 15.3 12.6 9.9 7.3
1000
72 20.6 2.7 18.3 15.3 12.3 9.3 6.3 #N/A #N/A
67 18.5 2.6
18.5 19.3 16.9 13.9 10.9 7.9 4.9
62 18.1 2.6
18.1 18.1 18.1 15.1 12.1 9.2 6.2
57 18.4 2.7
18.4 18.4 18.4 15.4 12.4 9.4 6.5
1.
These capacities are net capacities (the indoor fan heat is deducted).
ALL SENSIBLE CAPACITY
