York LX series Installation Manual

38
Model GPM
Pressure Drop (psi)
30°F 50°F 70°F 90°F 110°F
024 Full
Load
4 2.3 2.1 2.0 1.9 1.7
6 4.5 4.3 4.0 3.7 3.5
8 7.5 7.0 6.6 6.1 5.7
10 10.5 9.7 9.9 8.5 7.9
024 Part
Load
3 1.5 1.4 1.3 1.2 1.1
5 3.3 3.1 2.9 2.7 2.5
7 5.9 5.6 5.2 4.8 4.5
9 8.5 8.1 8.2 6.9 6.5
036 Full
Load
5 1.9 1.8 1.7 1.6 1.5
7 3.6 3.4 3.2 3.0 2.9
9 5.8 5.4 5.1 4.8 4.6
11 8.0 7.4 7.4 6.6 6.3
036 Part
Load
4 1.4 1.3 1.2 1.2 1.0
6 2.7 2.6 2.4 2.3 2.1
8 4.7 4.4 4.1 4.0 3.5
10 6.7 6.2 6.2 5.7 4.9
048 Full
Load
6 1.7 1.6 1.5 1.4 1.3
9 3.9 3.6 3.4 3.2 3.1
12 7.0 6.6 6.2 5.8 5.6
15 10.1 9.6 9.8 8.4 8.1
048 Part
Load
5 1.1 1.1 1.0 0.9 0.9
8 3.1 2.9 2.7 2.5 2.3
11 5.9 5.6 5.2 4.8 4.5
14 8.7 8.3 8.5 7.1 6.7
060 Full
Load
8 2.8 2.7 2.5 2.3 2.2
12 5.8 5.4 5.1 4.8 4.4
16 9.8 9.2 8.6 8.0 7.4
20 13.8 13.0 13.0 11.2 10.4
060 Part
Load
6 1.7 1.6 1.5 1.4 1.3
10 4.2 4.0 3.7 3.4 3.2
14 7.6 7.2 6.7 6.2 5.8
18 11.0 10.4 10.7 9.0 8.4
072 Full
Load
12 3.8 3.6 3.4 3.1 2.9
15 5.7 5.3 5.0 4.7 4.3
18 7.8 7.4 6.9 6.4 6.0
21 9.9 9.5 9.1 8.1 7.7
072 Part
Load
10 2.8 2.7 2.5 2.3 2.2
13 4.4 4.2 3.9 3.6 3.4
16 6.4 6.0 5.6 5.2 4.8
19 8.4 7.8 7.6 6.8 6.2
7/18/14
Pressure Drop
LX SERIES INSTALLATION MANUAL
