York LX series - Compressor and Thermistor Resistance

39
Thermistor Resistance
Compressor Resistance
Thermistor
Temperature (°F)
Microprocessor
Resistance (Ohms)
5 75757-70117
14 57392-53234
23 43865-40771
32 33809-31487
41 26269-24513
50 20570-19230
59 16226-15196
68 12889-12093
77 10310-9688
86 8300-7812
95 6723-6337
104 5480-5172
113 4490-4246
122 3700-3504
131 3067-2907
140 2554-2424
149 2149-2019
7/21/14
7/21/14
Model Compressor Model No.
208-230/60/1
Run Start
024 ZPS20K5E-PFV 1.21 - 1.39 1.52 - 1.75
036 ZPS30K5E-PFV 0.81 - 0.94 1.41 - 1.63
048 ZPS40K5E-PFV 0.48 - 0.55 1.72 - 1.99
060 ZPS51K5E-PFV 0.36 - 0.42 1.51 - 1.74
072 ZPS60K5E-PFV 0.31 - 0.36 1.72 - 1.98
7/21/2014
Note: Resistance at 77˚F
LX SERIES INSTALLATION MANUAL
