39JOHNSON CONTROLS
FORM 160.80-EG1 (808)
R-22 & R-134a UNITS
50 AND 60 HZ
SOLID STATE STARTER
WEIGHT
MOTOR WEIGHTS
NOTE: 1. Calculate total chiller weight by adding motor weight, solid state starter weight, and marine water box weights, if applicable.
2. Shipping weight includes refrigerant and oil charge. Operating weight includes water in tubes and water boxes.
3. Weights based on standard tubes in evaporators and condensers.
4. Operating weight based on R-22. Subtract difference in refrigerant charge if using R-134a.
shELL
CodE
EVaP.
– Cond.
CoM-
PrEs-
sor
shIP-
PInG
Wt.
(LBs.)
oPEr-
atInG
Wt.
(LBs.)
rEFrIG-
Erant
CharGE
(LBs.
r-22)
rEFrIG-
Erant
CharGE
(LBs.
r-134a)
Ea-Ea
S4 20,460 21,890 1,400 1,260
Ea-EB
S4 21,104 22,743 1,400 1,260
EB-Ea
S4 20,955 22,484 1,350 1,215
EB-EB
S4 21533 23337 1,350 1,215
EC-Ea
S4 21362 23139 1,300 1,170
EC-EB
S4 22,000 23991 1,300 1,170
Ea-Fa
S4 23,485 25592 1,520 1,368
Ea-FB
S4 24695 27192 1,520 1,368
EB-Fa
S4 23,914 26,180 1,520 1,368
EB-FB
S4 25,119 27,781 1,450 1,305
EC-Fa
S4 24,382 26,840 1,450 1,305
EC-FB
S4 25,592 28,435 1,450 1,305
Fa-Ea
S4 22,922 24,998 — 1,690
Fa-EB
S4 23,638 25,853 — 1,690
FB-Ea
S4 23,711 25,902 — 1,690
FB-EB
S4 24,288 26,757 — 1,690
FC-Ea
S4 24,171 27,076 — 1,620
FC-EB
S4 25,141 27,929 — 1,620
Fa-Fa
S4 25,977 28,655 2,000 1,800
Fa-FB
S4 27,187 30,256 2,000 1,800
FB-Fa
S4 26,626 29,552 2,000 1,800
FB-FB
S4 27,830 31,153 1,900 1,710
FC-Fa
S4 27,148 30,730 1,900 1,710
FC-FB
S4 28,688 32,325 1,900 1,710
shELL
CodE
EVaP
– Cond.
CoM-
PrEs-
sor
shIP-
PInG
Wt.
(LBs.)
oPEr-
atInG
Wt.
(LBs.)
rEFrIG-
Erant
CharGE
(LBs.
r-22)
rEFrIG-
Erant
CharGE
(LBs.
r-134a)
EA-EA S5 20,777 22,210 — 1,260
EA-EB S5 21,423 23,065 — 6/13/1903
EB-EA S5 21275 22807 — 1215
EB-EB S5 21853 23682 — 1215
EC-EA S5 21,681 23462 — 1,170
EC-EB S5 22,322 24317 — 1,170
EA-FA S5 23808 25919 — 1368
EA-FB S5 25,020 27,521 — 1,368
EB-FA S5 24,240 26,508 — 1,368
EB-FB S5 25,445 28,112 — 1,305
EC-FA S5 24,707 27,171 — 1,305
EC-FB S5 25,919 28,769 — 1,305
FA-EA S5 23,274 25,280 — 1,690
FA-EB S5 23,920 26,135 — 1,690
FB-EA S5 23,991 26,184 — 1,690
FB-EB S5 24,568 27,036 — 1,620
FC-EA S5 24,453 27,356 — 1,620
FC-EB S5 25,423 28,211 — 1,620
FA-FA S5 26,257 28,936 2,000 1,800
FA-FB S5 27,467 30,536 2,000 1,800
FB-FA S5 26,906 29,832 2,000 1,800
FB-FB S5 28,111 31,433 1,900 1,710
FC-FA S5 27,759 31,009 1,900 1,710
FC-FB S5 28,969 32,604 1,900 1,710
Motor CodE WEIGht
60 hZ 50 hZ (LBs)
CF 5 CC 1,080
CG 5 CC 1,080
CH 5 CD 1,120
CJ 5 CE 1,120
CK 5 CF 1,460
CL 5 CG 1,520
CM 5 CH 1930
CN 5 CI 1930
CP 5 CJ 1,980
CR 5 CK 1,980
CS 5 CL 2370
CT 5 CM 2,480
CU 5 CN 2,480
CV 5 CO 2,635
sIZE LBs
7L, 14L 200
26L, 33L 300
