York YS - Page 49

49JOHNSON CONTROLS
FORM 160.80-EG1 (808)
R-22 & R-134a UNITS
50 AND 60 HERTZ
SOLID STATE STARTER
WEIGHT
SIZE Kgs
7L, 14L 91
26L, 33L 136
MOTOR WEIGHTS
MOTOR CODE WEIGHT
60 Hz 50 Hz
(Kgs)
CF 5 CC 490
CG 5 CC 490
CH 5 CD 508
CJ 5 CE 508
CK 5 CF 662
CL 5 CG 689
CM 5 CH 875
CN 5 CI 875
CP 5 CJ 898
CR 5 CK 898
CS 5 CL 1,075
CT 5 CM 1,125
CU 5 CN 1,125
CV 5 CO 1,195
REFRIG- REFRIG-
SHELL
COM-
SHIP- OPER-
ERANT ERANT
CODE
PRES-
PING ATING
CHARGE CHARGE
COOLER
SOR
WT. WT.
(Kgs. (Kgs.
– COND. (Kgs.) (Kgs.)
R-22) R-134a)
EA-EA S5 9,424 10,074 — 572
EA-EB S5 9,717 10,462 — 572
EB-EA S5 9,650 10,345 — 551
EB-EB S5 9,913 10,742 — 551
EC-EA S5 9,835 10,642 — 531
EC-EB S5 10,125 11,030 — 531
EA-FA S5 10,799 11,757 — 621
EA-FB S5 11,349 12,484 — 621
EB-FA S5 10,995 12,024 — 621
EB-FB S5 11,542 12,752 — 592
EC-FA S5 11,207 12,325 — 592
EC-FB S5 11,757 13,050 — 592
FA-EA S5 10,557 11,467 — 767
FA-EB S5 10,850 11,855 — 767
FB-EA S5 10,882 11,877 — 767
FB-EB S5 11,144 12,264 — 735
FC-EA S5 11,092 12,409 — 735
FC-EB S5 11,532 12,797 — 735
FA-FA S5 11,910 13,125 907 816
FA-FB S5 12,459 13,851 907 816
FB-FA S5 12,205 13,532 907 816
FB-FB S5 12,751 14,258 862 776
FC-FA S5 12,591 14,066 862 776
FC-FB S5 13,140 14,789 862 776
REFRIG- REFRIG-
SHELL
COM-
SHIP- OPER-
ERANT ERANT
CODE
PRES-
PING ATING
CHARGE CHARGE
COOLER
SOR
WT. WT.
(Kgs. (Kgs.
– COND. (Kgs.) (Kgs.)
R-22) R-134a)
EA-EA S4 9,281 9,929 635 572
EA-EB S4 9,573 10,316 635 572
EB-EA S4 9,505 10,199 612 551
EB-EB S4 9,767 10,586 612 551
EC-EA S4 9,690 10,496 590 531
EC-EB S4 9,979 10,882 590 531
EA-FA S4 10,653 11,609 689 621
EA-FB S4 11,202 12,334 689 621
EB-FA S4 10,847 11,875 689 621
EB-FB S4 11,394 12,601 658 592
EC-FA S4 11,060 12,175 658 592
EC-FB S4 11,609 12,898 658 592
FA-EA S4 10,397 11,339 — 767
FA-EB S4 10,722 11,727 — 767
FB-EA S4 10,755 11,749 — 767
FB-EB S4 11,017 12,137 — 767
FC-EA S4 10,964 12,282 — 735
FC-EB S4 11,404 12,669 — 735
FA-FA S4 11,783 12,998 907 816
FA-FB S4 12,332 13,724 907 816
FB-FA S4 12,078 13,405 907 816
FB-FB S4 12,624 14,131 862 776
FC-FA S4 12,314 13,939 862 776
FC-FB S4 13,013 14,662 862 776
NOTE: 1. Calculate total chiller weight by adding motor weight, solid state starter weight, and marine water box weights, if applicable.
2. Shipping weight includes refrigerant and oil charge. Operating weight includes water in tubes and water boxes.
3. Weights based on standard tubes in evaporators and condensers.
