Zanotti DFZ - Digital Input Management; Digital Output Management

17
Digital input management MIN MAX
En Air pressure switch input enabling 01
En
Low pressure switch input enabling 01
Dis air fi lter input enabling 01
Dis Door input enabling 01
En Electric stand-by mode input enabling 01
En Water temperature input enabling 01
En Oil pressure alarm input enabling 01
En Thermal overload alarm input enabling 01
En High pressure switch input enabling 01
En Klixon input enabling 01
En Micro door switch input enabling 01
En Generator block input enabling 01
En Stand-by alarm input enabling 01
En Condenser fans block input enabling 01
cL Air pressure switch input polarity 01
oP Low pressure switch input polarity 01
cL air fi lter input polarity 01
op Door input polarity 01
cL Electric stand-by mode input polarity 01
cL Water temperature input polarity 01
cL Oil pressure alarm input polarity 01
cL Thermal overload alarm input polarity 01
oP High pressure switch input polarity 01
cL Klixon input polarity 01
oP Micro door switch input polarity 01
op Generator block input polarity 01
op Stand-by alarm input polarity 01
op Condenser fans block input polarity 01
Digital output management MIN MAX
0 Alarm relay 0 = Not Forced / 1 = Forced 0 1
1
3-ways solenoid valve 0 = Not Forced / 1 = Forced 0 1
0 Heating relay 0 = Not Forced / 1 = Forced 0 1
0 Evaporator fans relay 0 = Not Forced / 1 = Forced 0 1
0 High speed relay 0 = Not Forced / 1 = Forced 0 1
0 Electric motor relay 0 = Not Forced / 1 = Forced 0 1
1 Partialization relay 0 = Not Forced / 1 = Forced 0 1
1 Cooling relay 0 = Not Forced / 1 = Forced 0 1
0 Starter relay 0 = Not Forced / 1 = Forced 0 1
0 Alternator relay 0 = Not Forced / 1 = Forced 0 1
1 Heating2 relay 0 = Not Forced / 1 = Forced 0 1
0 Fuel pump relay 0 = Not Forced / 1 = Forced 0 1
0 Glow plug relay 0 = Not Forced / 1 = Forced 0 1
0 Condenser fan relay. 0 = Not Forced / 1 = Forced 0 1
0 Generator relay 0 = Not Forced / 1 = Forced 0 1
1 Anti-freezing relay 0 = Not Forced / 1 = Forced 0 1
0 Heating2 relay state when forced 0 = Off / 1 = On 0 1
0 3-ways solenoid valve relay state when forced 0 = Off / 1 = On 0 1
0 Partialization relay state when forced 0 = Off / 1 = On 0 1
0 Cooling relay relay state when forced 0 = Off / 1 = On 0 1
0 Anti-freezing relay state when forced 0 = Off / 1 = On 0 1
