5. Raccordement électrique
PE N L1 L2 L3 PE N L1 L2 L3
PE L1 L2 L3 PE L1 L2
Max
6 mm
2
Max 12 mm
Click!
Si vous installez le chargeur sur un
réseau en régime IT, consultez
zendesk.zaptec.com
Connectez chaque fil tout en pressant
fermement son levier vers le bas tel que
sur le schéma. Une fois les fils raccordés
en toute sécurité, replacez la languette
transparente et armez le disjoncteur.
Des bagues de serrages ne sont pas
obligatoires.
Dimensions du câble électrique
