191
Spanish
5. Conexión eléctrica
PE N L1 L2 L3 PE N L1 L2 L3
PE L1 L2 L3 PE L1 L2
Max
6 mm
2
Max 12 mm
Click!
Si está realizando la instalación del
cargador en una red de TI, consulte
zendesk.zaptec.com
Conecte todos los cables y presione
firmemente hacia abajo todas las palancas
como está ilustrado. Cuando los cables
estén conectados de manera segura,
vuelva a colocar la cubierta de terminales y
encienda el disyuntor.
Las férulas son opcionales.
Dimensiones del cable eléctrico
