Page #93 background image
93
Deutsch
15. Technische Daten
Mechanical and installation
PARAMETER TESTBEDINGUNGEN MIN. TYP MAX. EINHEIT
Abmessungen H: 242
W: 180
D: 75
mm
Gewicht 1.3 kg
Höhe 2000 m
Eingangskabelquer-
schnitt
1.5 6 mm
2
Eingangskabeldurch-
messer
9 18.5 mm
Schutzart IP54
Lademodus Modus 3, Gehäuse B
Mechanische Fes-
tigkeit
IK08
Grad der Ver-
schmutzung
Installationsumgebung 4
Halterung für
Belüftung
Gemäß DIN EN IEC 61851-
1 6.3.2.2
Nein
Zugang Gemäß DIN EN IEC 61851-
1 5.4
Beschränkter und uneinges-
chränkter Zugang
