29
Norsk
5. Elektrisk tilkobling
PE N L1 L2 L3 PE N L1 L2 L3
PE L1 L2 L3 PE L1 L2
Max
6 mm
2
Max 12 mm
Click!
Hvis du installerer laderen på et
IT-nettverk, kan du lese
zendesk.zaptec.com
Koble til alle ledningene og trykk
alle spakene hardt ned, som vist.
Når ledningene er godt festet,
monteres dekselet på terminalen igjen.
Slå på sikringen.
Bøssinger er ekstrautstyr.
Dimensjoner på elektriske ledninger
