137
Nederlands
5. Elektrische aansluiting
PE N L1 L2 L3 PE N L1 L2 L3
PE L1 L2 L3 PE L1 L2
Max
6 mm
2
Max 12 mm
Click!
Als u de oplader op een IT-netwerk
installeert, kijk dan op zendesk.zaptec.com
Sluit alle draden aan en druk alle hendels
stevig naar beneden. Zie de afbeelding.
Wanneer de draden veilig zijn vastgezet,
zet u het afdekkapje terug en schakelt
u de stroomonderbreker in.
Klemringen zijn optioneel.
Afmetingen elektriciteitsdraad
