ZAPTEC Go User Manual

13
English
To configure with the switch
Zaptec recommends that you use the
Zaptec App to configure the charger
whenever possible. However, you can
configure the charger without using
the app by using the switch. Note that
configuring this way will limit the
functionality of the charger:
• Circuit breaker value and available
power for charging is set to the same
value set by the switch
• It is not possible to set any phase
rotation. The default phases will be set
1-phase: L1 3-phase: L1, L2, L3 The
switch is located above the connector
terminal.
Switch configurations:
1 - 6 Amps
2 - 10 Amps
3 - 13 Amps
4 - 16 Amps
5 - 20 Amps
6 - 25 Amps
7 - 32 Amps
8 - Not in use
9 - Not in use
0 - Unconfigured or configured with App
0
5
1
2
3
4 6
7
8
9

ZAPTEC Go Specifications

General

Type	Electric Vehicle Charger
Charging Power	22 kW
Weight	1.3 kg
Protection Rating	IP54
Charging Standard	IEC 61851-1
Maximum Charging Power	22 kW
Protection Class	Class I
Current Output	32A
Connectivity	Wi-Fi, Bluetooth
Operating Temperature	-30°C to +40°C
Input Voltage	230/400V AC
Cable Length	Not included
