5. Ligação eléctrica
PE N L1 L2 L3 PE N L1 L2 L3
PE L1 L2 L3 PE L1 L2
Max
6 mm
2
Max 12 mm
Click!
Se estiver a instalar o carregador numa
rede de TI, consulte zendesk.zaptec.com
Conecte todos os fios e pressione
firmemente todas as alavancas conforme
ilustrado. Quando os fios estiverem
conectados com segurança, recoloque
a tampa do terminal e ligue o disjuntor.
As virolas são opcionais.
Dimensões do fio elétrico
