ZCS Azzurro 3000SP - 6.4.3. System Information

46 / 58
Identificazione: MD-AL-GI-00
Rev. 4.0 del 31.01.18 - Applicazione: GID
Manual of 11/06/2019 Rev. 1.8 “User Manual for 3000SP storage inverter”
2. List of historical events
Select “2. List of historical events” and press “OK” to access the information on the history of errors
in the memory; in particular, you will be able to view the number of errors, the identification code,
and date/time at which they occurred. Use the “Up” and “Down” keys to switch from one screen to
another in order to view all the errors. An example of the screen is shown below.
6.4.3. System Information
To enter the screen containing general information on the system, go back to the main menu and press
the “Menu/Back” key, scroll down with the arrow to item “3. System Info” and enter with the “OK” key.
You will then be able to enter the menu with information on the inverter and batteries. Scroll with the
“Up” and “Down” keys to view all the screens. An example of the screen is shown in the table below.
Note: the number and type of information may vary depending on the type of battery set.
System Info
System info (1)
Serial number
Serial number of the machine
Software version
Software version installed
Hardware version
Hardware version
RS485 address
Address of Wi-Fi communication
System info (2)
Country
Country code for the applicable
standard
Service Code
Firmware version installed
EPS
Information on EPS mode
Working mode
Information on working mode
System info (3)
DR.s0 Control
Information on DRMs0 mode
Set PF time
Response delay in frequency
Set QV time
Response delay in voltage
Power Factor
Power factor value
Battery parameters
(1)
Battery type
Battery model set
Battery capacity
Battery capacity in Ah
ID Events Intervention time
1. ID02 2018-03-16 09:56
2. ID03 2018-03-16 09:56
3. ID85 2018-03-05 21.45
4. ID52 2018-02-24 08.12
5. ID98 2018-02-15 17.34
