Zebra DS8178 User Manual

12 DS8178 Digital Scanner Quick Start Guide
LED Indications
123Scan
123Scan is an easy-to-use, PC-based software tool that enables rapid and easy customized setup of a scanner via
a bar code or USB cable. For more information, visit: www.zebra.com/123Scan
.
Utility Functionality
• Device configuration
• Electronic programming (USB cable)
• Programming bar code(s)
• Data view - scan log (display scanned bar code data)
• Access asset tracking information
• Upgrade firmware and view release notes
• Remote management (SMS package generation).
Indication LED Indicator
Hand-Held Scanning
Digital scanner is on and ready to scan, or no power
to scanner
Off
Bar code is successfully decoded Green flash
Transmission error Red
Hands-Free (Presentation) Scanning
No power to scanner Off
Digital scanner is ready to scan Green
Bar code is successfully decoded Off momentarily
Transmission error Red

Zebra DS8178 Specifications

General

Product color	Black
Housing material	-
International Protection (IP) code	IP42
Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	Photo diode
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 60 °
Optical sensor resolution	1280 pixels
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
PC connection	RS-232/USB
Wireless range	100 m
Bluetooth version	4.0
Standard interfaces	USB, RS-232, Bluetooth
Connectivity technology	Wired & Wireless
Battery life	83 h
Battery capacity	2500 mAh
Power source type	Battery

Weight and Dimensions

Depth	107 mm
Width	66 mm
Height	168 mm
Weight	235.3 g
