20
QLn Series User Guide
continued
Figure 6: Quad Charger
Charger Bay
Amber
Indicator
Green
Indicator
Power Supply
1. Slide Battery Pack into
Charger bay.
2. Rock Battery Pack into place.
Power Indicator
