Zebra VC80 Quick Reference Guide

Quick Reference Guide 11
Mounting Safety
Failure to install the mount correctly, or modifications to the mount, may result in
serious injury or damage to property. To ensure operator safety, you must use a
calibrated torque wrench and the supplied mounting hardware specific to the
VC80 model purchased when fastening the computer and mount. Use of a mount
in vehicles driven on public roads or highways is prohibited. Contact Zebra
Technical Support or your Zebra representative if you have a problem with mount
installation. For detailed mounting information, refer to the VC80 User Guide.
Ergonomics
Avoid Extreme Wrist Angles
Optimum Wrist Positions

Zebra VC80 Specifications

General

Display diagonal	10.4 \
Display resolution	1024 x 768 pixels
Touchscreen technology	Resistive
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Processor cache	2 MB
Processor cores	4
Processor model	E3845
Processor family	Intel Atom®
Processor frequency	1.91 GHz
Internal memory	4 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	mSATA
Storage media	SSD
Total storage capacity	128 GB
Certification	RoHS, WEEE, REACH compliant, IEC UL94-V0
Number of speakers	1
Card reader integrated	No
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Quantity per pack	1 pc(s)
RS-232 ports	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	Black
Operating system installed	Windows 10 IoT Enterprise
Operating system architecture	64-bit
Harmonized System (HS) code	84715000

Weight and Dimensions

Depth	90 mm
Width	235 mm
Height	265 mm
Weight	3900 g
