Introduction
Printer Media Compartment
2/26/10 ZM400 User Guide for UPS P1016807-001 Rev. A
Printer Media Compartment
Figure 4 shows the components inside the media compartment of your printer.
Figure 4 • Printer Components
1
Peel release lever
2
Printhead release latch
3
Media supply guide
4
Media hanger
5
Dancer assembly
6
Liner take-up spindle
2
6
5
1
4
3
