Remove Used Liner
2/26/10 ZM400 User Guide for UPS P1016807-001 Rev. A
Remove Used Liner
When you use the liner take-up option, you will periodically need to remove used liner from
the liner take-up spindle.
To remove used liner from the liner take-up spindle, complete these steps:
1. If the media has not run out, tear the liner before the liner take-up spindle.
2. Pull the liner release slide toward you until it stops (about a third of the way down the liner
take-up spindle).
3. Slide the used liner from the liner take-up spindle. Allow the liner release slide to return to
its position.
