Operations
Load Media
42
P1016807-001 Rev. A ZM400 User Guide for UPS 2/26/10
12.
13.
Set the printer to the appropriate print mode. See Select Print Mode on page 55 for
instructions.
14. Close the printhead assembly.
15. If the printer is paused (the Pause light is on), press PAUSE to enable printing.
Caution • Use the peel release lever and your right hand to close the peel assembly.
Do not use your left hand to assist in closing. The top edge of the peel roller/assembly
could pinch your fingers.
Close the peel assembly using the peel-off mechanism release lever.
