35
Operations
Print Modes and Printer Options
2/26/10 ZM400 User Guide for UPS P1016807-001 Rev. A
Media Paths
Table 9 shows the media paths for print mode and printer option combinations using roll
media. Fanfold media uses the same print modes and printer options as roll media.
Table 9 • Media Paths for Print Modes with Various Printer Options
Print Mode Printer Option Media Path
Tear-Off Printers with any
printer options can
use Tear-Off mode
Peel-Off Peel
Liner Take-Up
Red solid lines = media, Blue dotted lines = backing only
