Operations
Load Media
38
P1016807-001 Rev. A ZM400 User Guide for UPS 2/26/10
4. Feed the media under the dancer assembly (1), the upper media sensor (2), and the
printhead-open sensor (
3). Slide the media back until it touches the inside back wall of the
upper media sensor.
e. Slide in the media supply guide until
it touches the edge of the roll.
d. Flip up the media supply guide.
e. Slide in the media supply guide until
it touches the edge of the media.
Roll Media (Continued)
Fanfold Media (Continued)
13 2
