Operations
Load Media
40
P1016807-001 Rev. A ZM400 User Guide for UPS 2/26/10
8. Extend the media approximately 18 in. (500 mm) out of the printer.
9. Remove the exposed labels so that only the liner remains.
10. Feed the liner over the tear-off/peel-off bar (1) and behind the peel assembly (2). Make
sure that the end of the liner falls outside of the printer.
1
2
