zebris Medical GmbH FDM Technical Data and Operating Instructions Page 15/36
2.4 Specifications for the external power supply unit
All zebris FDM system can be operated by the same type of external power supply.
Input Output
100 - 240 V AC 16V DC
50 - 60 Hz 60 W
Cable Length
AC-Cable 1.7 m
DC-Cable 5 m
Pin arrangement / polarity
It is absolutely necessary to connect the external power supply unit
to a power outlet that contains a ground contact in order to secure
fault free and save operation of your FDM-T system. In case it is
necessary to use a mains adapter make absolutely sure that it has
ground contacts as well.
Be sure to position the measuring system in a way that allows easy
access to the power outlet at any time in case it is necessary to
disconnect the system from mains supply.
