Zeiss cinemizer OLED - HDMI 1.4 Frame Packing

35 Additional functions
VIDEO
3D-Mode
Aspect
Contrast
INFO
Connection
Status
ADVANCED
Auto Adjust
Man. Adjust
Man. Adjust
Brightness Bal
EXIT
Interleaved (L/R)
Interleaved (R/L)
Top/Bottom (L/R)
Top/Bottom (R/L)
ttt Back
HDMI
®
1.4 - frame packing
In the case of HDMI
®
1.4, unlike the previous
3D formats (side-by-side, top/bottom and line
interleaved) 2 complete images are transmitted
in the so-called "frame packing format". This is
only possible using the standard HDMI
®
1.4. If
a film or game in 3D is provided via HDMI
®
1.4,
the 3D mode in the cinemizer
OLED
video glasses
is activated automatically. It is not possible or
necessary to switch to the 3D mode, as the
playback device signals whether the content is
in 2D or 3D format. It is therefore not neces-
sary to make any changes on the menu item
"3D-Mode". In this case the settings menu is
not available.
L
R
2 complete images using frame packing
