Operation OPMI LUMERA® 700
Version 3.0
Page 190 G-30-1673-en
Typical procedure
• Adjust the brightness settings on the suspension system by starting with
the smallest value and slowly increase the brightness. Please observe the
max. permissible irradiation intensity (see page 22).
• Adjust the interpupillary distance and the eyepieces of the tubes (see
page 102).
• Swivel the surgical microscope across the operating field, while maintain-
ing an ergonomically favorable position.
• Press the XY reset button on the XY coupling. The executed functions de-
pend on the configured settings (see page 154).
CAUTION Risk of injury!
If the system has not been correctly balanced, unlocking of the magnetic
brakes may lead to uncontrolled upward or downward movement, causing
injury to the patient.
• Only open the magnetic brakes after the system has been balanced and
the surgical microscope remains stationary in all positions of the working
range (see page 87).
• Check the limitation of downward travel and maintain sufficient working
distance from the patient (siehe page 100).
• When unlocking the magnetic brakes, hold the system at the handgrips
to prevent it from unintentionally moving downward.
CAUTION Risk of injury when tilting the surgical microscope!
If you have mounted the RESIGHT fundus viewing system on the underside
of the microscope and steeply tilt the microscope, the RESIGHT fundus
viewing system may unintentionally move in and injure the patient.
• Remove the RESIGHT fundus viewing system before steeply tilting the mi-
croscope.
CAUTION Risk of injury!
If the foot control panel is accidentally activated, the exterior focus module
of the surgical microscope may move downwards and injure the patient.
• Ensure to provide sufficient clearance between equipment and patient
(min. 40 mm) when pressing the buttons of the foot control panel.
