Zendure Smart PV Hub 1200 Controller User Manual

2
Name
Smart PV Hub 1200
Controller
Model ZDSPVH1200
Weight ≈ 4.7 kg
Dimensions（L*W*H） 363×246×64 mm
Wireless Type Bluetooth, 2.4GHz Wi-Fi,
IP Level IP65
Warranty 10 Years
PV Input
Recommended Input Power 210-550W each
Maximum Input DC Voltage 60V
MPPT Voltage Range 16-48V
MPPT Full Power Voltage Range 31-48V
Min DC Input Voltage 16V
Max Input Current 2*13A
Number of MPPT 2
Output to Microinverter
Recommended Microinverter's Power 400-1200W
Rated Output Power 1200W
Max Microinverter Output Power 1200W
Rated Output Current 30A
Nominal Voltage Range 16-60V
AB1000 Input
Max Input Power 1200W
Max Input Current 25A
Rate Voltage 48V
Charging AB1000
Max Input Power 800W
Max Input Current 16.6A
Voltage Range 42-54V
Efciency
Output Efciency 98%
MPPT Efciency 99%
Working Temperature (° C) -20-45℃
