MAIN MOVING SYSTEM EM -39
DISASSEMBLY EBF99CFA
1. Disconnect the breather hose and the P.C .V. hose.
2. Loosen the center cov er bolts and then remove the
center cover.
3. Remove
the ignition coil assembly and the spark plug
cables
.
KCDC002B
4. Loos
en the cylinder head cover bolts and then remove
the c
ylinder head cover.
EDKE104A
5. Remove the camshaft sprocket.
6. Remove the camshaft bearing caps and timing chain.
EDKE124A
7. Remo
ve the camshaft.
8. Remove the HLA.
