Zenith ZPP 416 - Main Moving System; Cam Shaft

EM -38 ENGINE DOHC
MAIN MOVING SYSTEM
CAM S HAF T
COMPONENTS EE8F4E76
TORQUE : Nm (kg.cm, lb.ft)
5 ~ 8 (50 ~ 80, 4 ~ 6)
8 ~ 10 (80 ~ 100, 6 ~ 7)
12 ~ 14 (50 ~ 80, 4 ~ 6)
Bearing cap (rear)
Exhaust camshaft
HLA
80 ~ 100
(800 ~ 1000, 59 ~ 74)
Camshaft oil seal
Bearing cap (front)
Intake camshaft
Cylinder head
Gasket
Camshaft sprocket
EDDA018A
ZENITH POWER PRODUCTS - 416
