GENERAL EM -5

Description

Specification

Limit

Thermostat

Type

Valve opening temperature

Full-opening temperature

Waxpellettypewithjigglevalve

C (180 F)

C (203 F)

Engine coolant temperature sensor

Type

Resistance

Heat-sensitive thermistor type

2.31 ~ 2.59k

at 20 C(68 F)

146.9 ~ 147.3

at 110 C(230 F)

Air cleaner

Type

Element

Dry type

Un woven cloth type

Exhaust pipe

Muffler

Suspension system

Expansion resonance type

Rubber hangers

NOTE

O.D. = Outer Diameter

I.D. = Inner Diameter

O.S. = Oversize Diameter

U.S. = Undersize Diameter
