LUBRICATION SYSTEM EM -71
CAUTION
• Apply sealant a pprox. 4mm (0.16 in.) in thick-
ness.
• After application of sealant, do not exceed 15
minutes before installing the oil pan.
ECDA018D
6. Install the oil pan and tighten the bolts to the specified
torque.
Tightening torque
Oil pan bolt : 10 ~ 12 Nm (100 ~ 120 kg.cm, 7 ~ 9 lb.ft)
ZENITH POWER PRODUCTS - 416
