zenpert 3R20 - Print Specifications

4
 Auto-switching AC adapter
Note: The printer will automatically turn off when stopping
operation after 30 minutes.
Battery
Output
7.4V
Capacity
2000mAh
Charging time
2hrs
Environmental
condition
Operation Temperature: 0 ~ 40˚C (32 ~ 104˚F)
Storage Temperature: -20 ~ 60 ˚C (-4 ~ 140˚F)
Relative Humidity:
- Operation: 10% to 85% non-condensing
- Storage: 5% to 90% non-condensing
Drop 1.5 m (4.9 ft) w/o environmental case
Environmental
concern
Comply with RoHS, WEEE, and REACH
1.4 Print Specifications
Print Specifications
3R20
Print head resolution 203 dots/inch (8 dots/mm)
Printing method
Direct thermal
Dot size
(width x length)
0.125 x 0.125 mm(1 mm = 8 dots)
Print speed
(inches per second)
Max. 2 ips (50.8 mm/sec)
Max. print width 72 mm (2.83")
Max. print length
Continuous receipt paper: 2,794
mm
(110”)
(associate with DRAM)
Printout bias
Vertical: Max. 1 mm
Horizontal: Max. 1 mm
