Effects Operation
An effect is output directly through the Effects
Master. The speed and attack of a sequence may
be decided before the chase sequence is
transferred to the outputs, or modified directly
while the sequence is running.
Effects Operating Controls
SEQUENCE + / - :
Selects one of the sequences or Audio Effects. In
Run, both pressed selects the first programmed
sequence, or ‘A’ if there is no programmed
sequence.
EFFECT DRIVE:
Selects Auto,Varispeed, or Bass Chase; for an
Audio Effect, selects ‘Sound to Light’ or
‘Ripplesound’ type effects.
ATTACK :
Determines type of crossfade between steps of a
chase or the type of Audio Effect.
SPEED:
Sets the speed of the chase sequence or the rate
of attack of an Audio Effect.
EFFECTS MASTER:
Sets maximum output level for an effect.
PREVIEW :
Displays effect on preview leds.
GO:
Outputs next step of stopped chase sequence.
FLASH:
Flashes/Solos the effect.
NOTES
*
Auto / Varispeed / Bass Chase
Auto Chase requires no sound input, with Chase Speed
determined directly by the speed control. Varispeed speeds
up and slows the chase according to the tempo of the music
on the audio input, with the speed control used to set a basic
speed. Bass Chase will step through the pattern on a bass
beat giving a Sound to Light effect.
NOTES (Continued)
*
Attack
Three types of crossfade are available:
Switch on / switch off
Switch on / fade off
Fade on / fade off
Switch on / fade off is particularly useful for PAR cans
*
Sequence Display shows only sequences that
have been programmed.
When turning the Mode switch from Program or Presets to
Run, only sequences that have been programmed will be
shown on the Sequence display.
If none are programmed, the display will show ‘A’ for the
Audio Effect.
If say 2, 5 and 7 are programmed, ‘2 ‘will be displayed and
only 2,5,7 or A may be selected.
/p14/3
Effects Operation
Page 14 7359500/p14/3
