3.1.3 CAMERA
The camera for the Titan will need to be connected. Once installed,
it is advised that this camera is not removed and reconnected as this
can potentially damage the camera connection.
1. To attach the camera align the notches on the top of the camera
with the slots on the under side of the Titan drone and slide the
camera back into position ensuring that the camera is secure.
2. To connect the Micro USB connection, connect one end of the
supplied cable to the camera while supporting the camera with
your other hand. Then Connect the other end of the micro USB
cable to the Titan drone.
3.1.4 INSTALLING A MICRO SD CARD
1. With the Titan facing away
from you, insert the Micro
SD Card (Micro SD Card not
included) into the side of the
camera ensuring that the text
side of the Micro SD Card is
also facing away from you.
2. While supporting the camera,
gently press the card in until you hear the lock click into place.
