Controls and Components
3.7
A. Rear Brake Fluid Reservoir
See “
Rear Brake Fluid Reservoir”, on page 6.11.
B. Auxiliary Power Pack Charging Connection
For description and operation, see “
Quick Charging
(Off-Board Accessory Charger)”, on page 5.6. The
auxiliary connector is located above the motor.
C. Power Pack
For description and operation, see “
Power Pack”, on
page 5.1.
D. Rear Brake Pedal
The rear brake pedal controls the rear brake when the
pedal is pressed. When braking, the throttle should be
in the closed position. The brake light illuminates
when the rear brake pedal is applied.
E. Brushless Motor Controller
Precisely “meters” the flow of electricity from the
power pack to the motor according to the action of the
throttle and surrounding conditions.
F. Drive Belt Tension Adjuster
Located on left and right side. See “
Gates® Carbon
Drive™ Smartphone Application”, on page 6.19 for
additional information.
