Controls and Components
3.5
A. Headlight
• For headlight operation, see “
Handlebar Controls”, on
page 3.17.
• For headlight bulb replacement, see “
Headlight Bulb
Replacement”, on page 6.23.
• For headlight alignment, see“
Headlight Alignment”,
on page 6.23.
B. Front Turn Signal
• For turn signal operation, see “
Handlebar Controls”,
on page 3.17.
• For turn signal light bulb replacement, see “
Turn
Signal Light Bulb Replacement”, on page 6.25.
C. Brake/Tail Light
For brake/tail light bulb replacement, see “
Brake/Tail
Light Bulb Replacement”, on page 6.26.
D. Rear Turn Signal
For turn signal operation, see “
Handlebar Controls”,
on page 3.17.
E. Drive Belt Tension Adjuster
For the drive belt adjustment procedure, see “
Drive
Belt Adjustment Procedure”, on page 6.19.
F. Kickstand Switch
This switch is a safety feature that prevents motor
operation when the kickstand is down. If the kickstand
were down when riding it could contact the ground
causing you to lose control of the motorcycle and
cause personal injury.
CAUTION: Park only on a flat firm surface, otherwise the
motorcycle could fall over causing damage.
G. Kickstand
The kickstand swings out from the side and supports
the motorcycle when parked. The key switch should
be in the OFF position when parked.
H. Integrated Power Pack Charger
For description and operation, see “
Power Pack”, on
page 5.1.
Zero Owner's Manual (FX and FXS).book Page 5 Monday, September 11, 2017 10:13 AM
