Power Pack and Charging
5.3
Power Pack Swapping (if equipped)
Dependent upon specification, some Zero FX and FXS
motorcycles feature a quick change power pack. This
allows the rider to charge one power pack while using
another.
CAUTION: Do not operate the motorcycle without the
power pack rail or rail fastener in place.
To remove the power pack:
1. Remove the key from the key switch and safely support
the motorcycle.
2. Grasp the top of the key lock latch (see arrows) and pull
downward to unlock the power pack rail.
3. Pull the power pack rail (A) away from the motorcycle.
4. Using a firm grip, slide the power pack out of the frame.
Note: If necessary, assist removal by also pushing battery
from opposite side of the motorcycle.
Note: The power pack weighs 42 lbs (19 kg).
To Install the power pack:
1. Slide the power pack into the frame.
2. Re-attach the power pack rail.
3. Push the key lock upward to secure the rail.
4. (Optional) Use the key to lock the rail.
WARNING! Opening of the power pack is for trained Zero
Motorcycles technicians. Please be aware that incorrect
handling of a Zero power pack can be dangerous. DO
NOT OPEN!
Zero Owner's Manual (FX and FXS).book Page 3 Monday, September 11, 2017 10:13 AM
