Controls and Components
3.7
A. Drive Belt
For description and operation, see “
Drive Belt”, on
page 6.16.
B. Drive Belt Tension Adjuster
For the drive belt adjustment procedure, see “
Drive
Belt Adjustment Procedure”, on page 6.19.
C. Power Pack Rail Latch
For description and operation, see “
Power Pack
Swapping (if equipped)”, on page 5.3.
D. Power Pack
For a description, see “
Power Pack”, on page 5.1.
E. 12V Fuse Center
For a description, see “
Fuses”, on page 6.30.
F. Power Pack Charger
For a description, see “
On-Board Power Pack
Charger”, on page 5.4.
G. Rear Brake Pedal
The rear brake pedal controls the rear brake when the
pedal is pressed. When braking, the throttle should be
in the closed position.
H. Rear Brake Fluid Reservoir
For a description, see “
Brake Fluid Level Inspection”,
on page 6.10.
Zero Owner's Manual (FX and FXS).book Page 7 Monday, September 11, 2017 10:13 AM
