eZ80
®
CPU
User Manual
UM007714-0908
CPU Instruction Set
117
CCF
Complement Carry Flag
Operation
C
←
~C
Description
The Carry Flag bit (C) in th
e F register is inverted.
Condition Bits Affected
Attributes
S
Not affected.
Z
Not affected.
H
Previous carry is copied.
P/V
Not affected.
N
Reset.
C
Set if carry was cleared to 0 before operation; reset otherwise.
Mnemonic
Operand
ADL Mode
Cycle
Opcode (hex)
CCF
—X
1
3F
125
